3 Wire Remote Activated Electronic Time Delay Switch

  • Saves cost and energy
  • Easy to fit
  • For loads up to 16A
  • Adjustable from 2 minutes to 2 hours
  • Works in conjunction with all Elkay slave switches
  • Neutral required
  • Suitable for use with a 25mm BS back box
  • Please note: LEVPFCC capacitor will often be required when switching certain types of loads
Cefco 320a 120240329 2755 uzs0s
  • Part Code: 320A-1
  • Stock Code: 0704-0059
Specification
Available Options Variety of Different Operation Types Available such as Pushbutton, Touch and PIR
Colour White
Compliance CE
Current Rating 16A
Depth 8mm
Dimensions (H)85 mm x (W)85 mm x (D)8 mm
Finish Glossy
Guarantee 6 Years
Height 85mm
Logistics Partner NONE
Material ABS
Mounting Wall
Number Of Wire Connections 3
Packaging Types Pack
Product Range Energy Sense
Similar Stock No
Standards BS EN 60669-2-3:2006 (Ed 4), BS EN 60669-2-1 2002 (Ed 3), BS EN 60669-1 1998 + A1:1999
Suitable For Resistive, Incandescent, Fluorescent, Compact Fluorescent and LED Loads
Tamper Proof Yes
Timer Range 2 mins - 2
Type Remote
Unspsc 39122208
Unspsc V13 39122208
Unspsc V18 39122208
Unspsc V22 39122208
Voltage Rating 230V
Weight 0.168kg
Width 85mm
